_Easy

>

EWH 100

Water hearter of vertical installation with temperature thermostat in 100 litres

REF. 42080100
EAN. 8421152069424
Select a colour: White
White
  • Extremely resistant anamel coated tank
  • Scale-preventing magnesium anodes on the inside
  • Thermostat

5 year warranty

Comfort and tranquility in your home are most important, and why we offer 5 year warranty on all our thermoses.
5 year warranty

More resistant

Their tanks are composed of three layers enamel and stainless steel resistors sapphire enamel durability, lengthening its useful life.
More resistant

Greater protection, more security

System incorporates moisture protection, safety valve, overheating protection and anti-heat protecting dry.
Greater protection, more security

Designed to save

SmartControl system incorporates, learning cycles based on consumption and it provides heating patterns consistent with the user consumption routines, achieving significant electricity savings.
Designed to save

Space is no longer a problem

Slim thermos feature a compact design for smaller spaces. In addition, they can be installed vertically or horizontally, making them the most versatile solution that fits into any corner of your smaller with their Thermos Slim hogar.pacios.
Space is no longer a problem
  • Capacity: 100 litres
  • Sapphire enamelled tank
  • Sapphire heating element
  • Electrolytic muff
  • Regulation of temperature: 30-75 ºC
  • Pressure valve > 5 bar
  • Max. Input temperature: 0,75Mpa
  • Thermometer
  • Anti Over-pressure protection
  • Overheat protection
  • Anti Dry-heating Protection
  • Waterproof Grade: IPX4
  • Rated power output 1500 W
  • Thickness of insolation: 20mm
  • Water connection: G½
  • Average number of users : 1-2/2-3/2-4/3-5

General measures

  • Product height (mm): 1005
View technical drawing

EU Regulation No. 812/2013

  • Annual energy consumption AEC kWh/annum (kWh): 1424
  • Sound power level L WA (dB): 15
  • Thermostat temperature settings Tout of the box (ºC): 75
  • Declared load profile: M
  • Water heating energy efficiency class: C

EU Regulation No. 814/2013

  • The Mixed Water at 40 °C V40 L (L): 127
  • Storage Volume V L (L): 100

Manuals
Technical drawing
High res images
Energy label
